Data Import and Export

Emma provides powerful tools for importing data into Infrahub from CSV files and exporting Infrahub data back to CSV format. This enables efficient migration from existing systems and data sharing between tools.

Data Exporter

Data import​

The Data Importer allows you to upload CSV files and map their columns to Infrahub schema attributes, enabling you to bulk-load infrastructure data.

Supported file formats​

  • CSV files with headers
  • UTF-8 encoding (recommended)
  • Common delimiters: comma, semicolon, tab
  • File size: Up to 100MB per upload

Import process​

Step 1: Prepare your data​

Ensure your CSV file:

  • Has column headers that match the names of the attributes and relationships in your schema. Columns are matched by name, so a header that matches nothing is reported and ignored. Surrounding whitespace in a header or a value is stripped.
  • Contains clean data with consistent formatting
  • Includes required fields as defined by your schema
  • Uses consistent values for relationships and enums

Example CSV structure:

name,model,serial_number,location,ip_address,status
switch-01,Cisco 3850,FCW2140L0EF,datacenter-1,192.168.1.10,active
switch-02,Cisco 3850,FCW2140L0EG,datacenter-1,192.168.1.11,active

Step 2: Upload​

  1. Choose the target kind from your Infrahub instance
  2. Select your CSV file using the file upload interface

Columns are matched to the schema by name; there is no manual mapping step.

Step 3: Preview and validate​

Emma checks the file against the schema and shows what it found:

  • Errors stop the import. A missing mandatory column, or a relationship reference that matches no object, is reported against the line it came from.
  • Warnings do not stop the import. A column that matches nothing in the schema is reported and left out of the data sent to Infrahub.

If there are no errors, the resolved rows are shown in an editable table, so values can be corrected before the import runs.

Step 4: execute import​

After reviewing the preview:

  1. Confirm the import by selecting Import Data
  2. Review the results, which name each object created and each row rejected by Infrahub, followed by a count of how many of the rows were imported

Advanced import features​

A column that matches a relationship in the schema references an object that already exists in Infrahub. Emma resolves every reference before the import runs, and reports the line number of any reference it cannot match.

Reference by human-friendly ID:

Emma looks the value up under the kind the relationship points at, so a site relationship pointing at LabSite resolves rtp1 to the LabSite named rtp1:

site,name,height_u
rtp1,R101,42
sjc2,R201,45

If the target's human-friendly ID has several components, join them with __: a rack identified by its site and its own name is written rtp1__R101.

A UUID is also accepted, and is used as-is with no lookup.

Reference by kind and human-friendly ID:

Prefixing the value with a kind (LabSite__rtp1) overrides the kind declared by the relationship. This is required when the relationship points at a generic, because the concrete kind of the target cannot be inferred:

name,endpoint
cable-01,LabInterface__switch-01__Ethernet1

Cardinality-many relationships:

Write a list, and each entry is resolved in turn:

name,tags
switch-01,"['production', 'edge']"

An empty cell, [], or "" leaves the relationship unset.

Data export​

The Data Exporter extracts data from Infrahub and formats it as CSV files for use in other tools or for backup purposes.

Export options​

Schema-based export​

Export all objects of a specific schema type:

  1. Select schema from your Infrahub instance
  2. Choose attributes to include in the export
  3. Configure relationship handling (include related object details)
  4. Set filtering criteria to limit exported records

Query-based export​

Export data using custom filters:

  • Field filters - Filter by specific attribute values
  • Date ranges - Export data from specific time periods
  • Relationship filters - Filter based on related object properties
  • Complex queries - Combine multiple filter criteria

Bulk export​

Export multiple schema types in a single operation:

  • Related schemas - Export parent and child objects together
  • Dependency order - Automatic ordering for reimport compatibility
  • Consistent snapshots - Ensure data consistency across exports

Export formats​

Emma supports multiple CSV format options:

Standard CSV:

  • Comma-separated values
  • Header row with attribute names
  • UTF-8 encoding

Customizable Format:

  • Custom delimiters
  • Quote character options
  • Line ending preferences
  • Character encoding selection

Relationship Handling:

  • Flatten relationships into columns
  • Include relationship IDs
  • Export related object details

Advanced export features​

Incremental export​

Export only changes since last export:

  • Timestamp-based - Export records modified after a specific date
  • Change tracking - Export based on Infrahub's change tracking
  • Delta exports - Include only modified fields

Scheduled exports​

Configure automated exports:

  • Recurring schedules - Daily, weekly, monthly exports
  • Event-triggered - Export on data changes
  • Multiple formats - Generate different exports for different consumers

Data quality and validation​

Import validation​

Emma validates imported data against:

  • Schema definitions - Ensure data matches expected structure
  • Data types - Validate numeric, date, and other typed fields
  • Constraints - Check uniqueness, required fields, and custom rules
  • Relationships - Verify referenced objects exist

Export verification​

Exported data includes:

  • Metadata - Export timestamp, schema versions, record counts
  • Integrity checks - Checksums for data verification
  • Audit trail - Information about data source and transformation

Best practices​

Import best practices​

  1. Validate data quality before import using external tools
  2. Start with small batches to test mappings and validations
  3. Use consistent naming for relationship references
  4. Clean up data to remove duplicates and inconsistencies
  5. Backup Infrahub before large imports

Export best practices​

  1. Document export purposes to choose appropriate options
  2. Test import compatibility if exporting for reimport
  3. Use incremental exports for regular synchronization
  4. Include metadata for audit and tracking purposes
  5. Validate exported data before using in downstream systems

Performance optimization​

  1. Use appropriate batch sizes (typically 100-1000 records)
  2. Limit concurrent operations to avoid overwhelming Infrahub
  3. Monitor system resources during large operations
  4. Use filtering to export only necessary data
  5. Schedule large operations during low-usage periods

Integration scenarios​

Common use cases​

Migration from Legacy Systems:

  • Export data from existing tools to CSV
  • Transform and clean data as needed
  • Import into Infrahub schemas

Data Synchronization:

  • Regular exports to external systems
  • Incremental updates based on changes
  • Bidirectional synchronization workflows

Backup and Recovery:

  • Full data exports for backup purposes
  • Schema-consistent exports for disaster recovery
  • Point-in-time data snapshots

Reporting and Analytics:

  • Export data for business intelligence tools
  • Create regular data extracts for reporting
  • Integration with data lakes and warehouses

Integration with other Emma features​

  • Schema Library - Use library schemas as import targets
  • Schema Builder - Create schemas for imported data
  • Schema Visualizer - Understand data relationships before import/export

Troubleshooting​

Common import issues​

File Upload Problems:

  • Check file size limits (100MB maximum)
  • Verify file format and encoding
  • Ensure proper CSV structure with headers

Mapping Errors:

  • Verify schema attribute names
  • Check data type compatibility
  • Review required field mappings

Validation Failures:

  • Check data quality and formatting
  • Verify relationship references exist
  • Review constraint violations

Performance Issues:

  • Reduce batch sizes
  • Check network connectivity
  • Monitor Infrahub resource usage

Common export issues​

Missing Data:

  • Verify user permissions for accessed schemas
  • Check filtering criteria
  • Review relationship configurations

Format Problems:

  • Verify encoding settings
  • Check delimiter configuration
  • Review quote character handling

Performance Issues:

  • Use filtering to reduce data volume
  • Increase timeout settings
  • Monitor export progress

For detailed troubleshooting, see the Troubleshooting Guide.
